12V DIY 520nm Focusable Green Module with PWM Control
5.0 (41 items)
Limited Time SaleUS$101.40 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 210186310 | Release Date | 2026/04/02 | List Price | US$67.60 | Model Number | 210186310 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Technical Parameters: wavelength: 520nm Spot type: retangular dotted (adjustable) Size: (33*70mm) Drive mode: external ACC constant current drive Cooling method: forced air cooling Operating voltage: 12V DC Control interface: 3pin (12V+ GND- PWM) Shell material: aluminum, surface anodized Collimator lens: optical glass coating PACKING LIST: Green Light Module*1 3PIN CABLE*1 3PIN TO 4PIN CABLE*1 DC to 3pin Connector 12V 2A AC/DC Adapter SAFETY GLASSES*1
- Wave Length: 520nm(+-8nm), 1, (W), Beam Diameter: about 5mm, Very bright! Duty Cycle: 2 hours on, 0.5 hours off.
- Frequency: <18khz, PWM/TTL: 0-5V , Red wire=12V+, black wire= GND , yellow wire= PWM+ , white wire=PWM- .
- When using a PWM transmitter, please make sure you have connected its + and - correctly, and remember PWM must be 5V
- This module has a rectangular spot/dot, the beam is flat!
- This module comes with 12V 2A DC adapter , you can connect it to 110-240V power source directly.
| UPC | 767461754322 |
|---|---|
| Color | Green |
| Brand Name | oxlasers |
| Style Name | Standard |
| Manufacturer | shanghai zhuo long dian zi you xian gong si |
| Material Type | Aluminum, Glass |
| Item Type Name | green module |
| Operation Mode | Manual |
| Included Components | AC/DC adapter *1, Green Module*1, cables* 3 |
