Mini welding positioner 10/5 kg, welding rotary table for welding tube workpiece turntable with welding chuck

Input voltage: 220V 50HZMaximum load: 10/5kgWorkbench tilt angle: 0-90°Workbench diameter: 180MMWorkbench speed: 2-10/1-7 rpmWelding current: 80ADrive motor: DC24V 20WWorkbench flip: manualRotation motor: 20WDimensions: 320*270*230mmPackage1x Rotary welding positioner turntableAll accessories

• [Stepless speed regulation] The rotating structure of the welding positioner is driven by a 20W DC motor, which can achieve stepless speed regulation.
• [Small and light] The welding table range of the rotary table is 0~90°, and the flip angle is locked safely and stably. It is suitable for small workpieces and can achieve welding at any angle.
• [Easy to operate] The rotary welding positioner foot switch table rotates, which is easy to operate.
• [Fixed welding gun position] The welding turntable can be equipped with a welding chuck and a welding gun adjustment mechanism to fix the welding gun position. It can also be equipped with a pneumatic tail top to keep the two ends of the workpiece concentric.
• [Easy to use] The clamp and the workbench adopt a simple mechanical connection method with high positioning accuracy; precise structure, easy operation, and flexible use.
